KCSGP-600-500-K60-W 60mm Hole Diameter Vision Working Panel Back Light With Collimated Film Machine Vision Illumination, Maker: KCS
Specifications
Model:
KCSGP-600-500-K60-W
Maker/Brand:
KCS
Category:
Notes:
Hole Diameter Vision Working Panel Back Light With Collimated Film Machine Vision Illumination
|
Color (Wavelength)
|
Red:620-630nm
|
Green:525-530nm
|
Blue:465-470nm
|
|
White color temperature: 6600-7000K
|
UV:365/385nm
|
IR:850/940nm
|
|
|
Operating environment
|
Temperature: 0 to 50 ℃, Humidity: 20% to 85% RH
|
||
|
Life time
|
100,000hrs theoretical service time(Depends on the operating environment, not a guarantee.)
|
||
|
Compatible Control Unit
|
Analog Controller, Digital Controller, Constant Current Controller
|
||
|
Optional Accessory
|
1. Lights source and lens adaptor. For machine vision lighting.
|
||
|
2. Diffusion plate, Polarizing plate.(Opational transmittance:60%,70%,80%,90%)
|
|||
|
3. Extension cable: 1m/2m/5m/10m/15m(2 kinds of materials of the shell of wire:PVC of hardness;silicone of softness.)
|
|||
|
Warranty
|
One year warranty, Free samples and technical support(buyers pay for the freight)
|
||
|
Lights customization
|
Provide design and development service according to individual needs of customers. Reach the best image effects.
|
||
- IP Rating: Customized
- Color Temperature(CCT): 6000K (Daylight Alert)
- Warranty(Year): 1-Year
- Power Supply: DC
- Power Source: DC
- Lamp Body Material: aluminum alloy
- Feature: dimmable
- Beam Angle(°): Customized
- Input Voltage(V): DC 24V
- Lamp Luminous Efficiency(lm/w): Customized
- Lamp Luminous Flux(lm): Customized
Working Temperature(℃): 0-40 - Color Rendering Index(Ra): Customized
- Model Number: KCSGP-600-500-K60-W
- Brand Name: KCS
- Emitting Color: White
- Light Source: LED
- Support Dimmer: Yes
- Color: White
- Lighting solutions service: Lighting and circuitry design
- Lifespan (hours): 30000
